Max 8,0 Ton

Bearing structure made of steel with four wheels

Nr. 2 removable counterweights of 1,300 kg each

Nr. 2 Front tires 250-15″
Nr. 2 Rear tires 23×9-10″

Front with 2 motors AC of 4.2kW each

Max pressure 220 bar with AC motor of 12kW

Front electro-hydraulic

Rear 180°

Made of high-quality steel, octagonal section consisting of three direct control telescopic elements with double cylinder. Four-position tilting head as standard.

80V 560Ah with automatic topping up and charger on board

Radio control of traction / aerial part

Electronic load limiting system with display for load and boom position monitoring

8.400 kg

Extendable wheelbase, front stabilizer bar, hydraulic winch, hydraulic swing jib, non-marking wheels, self-leveling hydraulic forks

Brochure
