Max 90 ton

Supporting structure made of steel

Removable n ° 4 of 3,250 kg each.

Front tire 6 cushion 840×320
Rear tires nr ° 2 from 400 / 60-15 “

Rear with electrically powered oscillating differential 48kW 96V engine

Max pressure 250 bar with 26kW 96V motor

Electro-hydraulic on 4 front wheels and 2 rear wheels

Rear 160 ° dedicated motor 20kW 96V pressure 120 bar

Made of high quality steel, composed of four elements: base arm and three telescopic sections with sequential hydraulic extension. Two-position tilting head as standard.

Removable from 96V 1250Ah with automatic topping up

Electro proportional joystick in the driving position

Electronic load limiting system with display for load and boom position display

45.000 / 32.000 kg (without ballast)

Traction / aerial part radio control, hydraulic winch, hydraulic swing jib, self-leveling hydraulic forks, closed cabin
