Max 9.000 kg

Supporting structure made of steel with four independent hydraulic stabilizers

70CV, 4-cylinder, water-cooled diesel

With rubber tracks n ° 2 hydraulic traction motors with variable displacement

Hydrostatic max speed 4 km/h

Max pressure 280 bar
Gear pump, electric proportional distributor

Made of high quality steel, composed of four elements: base arm and three telescopic sections with sequential hydraulic extension. Two-position tilting head as standard.

Electro-proportional controls controlled by pedal in the cabin for traction and joystick for the aerial part

Electronic load limiting system with display for load and boom position display

10.000 kg

Traction / aerial part radio control, hydraulic winch, folding hydraulic jib, non- marking tracks

Brochure
