Levertijd in overleg
| Capaciteit | 0.995t x 1.3m |
| Reikwijdte | 9.9m x 0.18t |
| Hefhoogte hoog | 11.3m |
| Hefhoogte laag | -66.5m |
| Outrigger Max. Extended Width | (Lateral) 4,580mm x (Front) 4,530mm x (Rear) 3,810mm |
| Travel speed | 0-2.0km/h |
| Travel Ground Pressure (MK1033CW-1) | 57.6kpa [0.59kgf/cm2] |
| Travel Ground Pressure (MK1033CWEH-1) | 59.6kpa [0.61kgf/cm2] |
| Engine | YANMAR 2TNV70-NMBA / Diesel |
| Engine Rated Output | 7.4kw/2,500rpm |
| Electric Motor | 5.5kw, 4P 380V |
| Dimensions (MK1033CW-1) | 2,900mm (L) x 750mm (W) x 1,955mm (H) |
| Dimensions (MK1033CWH-1) | 3,030mm (L) x 750mm (W) x 1,990(1,955)mm (H) |
| Dimensions (MK1033CWE-1) | 3,235mm (L) x 750mm (W) x 1,955mm (H) |
| Dimensions (MK1033CWEH-1) | 3,235mm (L) x 750mm (W) x 1,990(1,955)mm (H) |
| Machine Weight (MK1033CW-1) | 2,290kg (2,000kg) |
| Machine Weight (MK1033CWH-1) | 2,390kg |
| Machine Weight (MK1033CWE-1) | 2,270kg |
| Machine Weight (MK1033CWEH-1) | 2,370kg |
| Document |
All our cranes include a range of standard equipment that ensure the
safety, functionality and usability of the cranes are unsurpassed.
