Levertijd in overleg
| Capaciteit | 8.09t x 2.4m |
| Reikwijdte | 18.8m x 0.34t |
| Hefhoogte hoog | 19.6m |
| Hefhoogte laag | -21.0m |
| Outrigger Max. Extended Width | (Lateral) 6,770mm x (Front) 6,300mm x (Rear) 6,520mm |
| Pick & Carry Capacity | 1,000kg |
| Travel Ground Pressure (MC815CRM) | 52.0kpa [0.53kgf/m2] |
| Travel Ground Pressure (MC815CRME) | 53.0kpa [0.54kgf/m2] |
| Engine | YANMAR 4TNV88C-NMB / Diesel |
| Engine Rated Output | 30.5kw/2,500rpm |
| Electric Motor | 15kw, 4P 380V |
| Dimensions | 5,900mm (L) x 1,670mm (W) x 2,490mm (H) |
| Machine Weight | 9,460kg (9,700kg with electric motor) |
| Document |
All our cranes include a range of standard equipment that ensure the
safety, functionality and usability of the cranes are unsurpassed.
