Levertijd in overleg
| Capaciteit | 2.82t x 1.4m |
| Reikwijdte | 8.205m x 0.15t |
| Hefhoogte hoog | 8.7m |
| Hefhoogte laag | -10.1m |
| Outrigger Max. Extended Width | (Lateralï¼4,782mm x ï¼Frontï¼4,718mm x ï¼Rearï¼3,990mm |
| Travel Speed | 0-2.2km/h |
| Travel Ground Pressure (MC285CWM-3) | 50.0kpa (0.510kgf/cã¡) |
| Travel Ground Pressure (MC285CWME-3) | 54.3kpa (0.554kgf/cã¡) |
| Engine | ANMAR 2TNV70-NMBA / Diesel |
| Engine Rated Output | 7.4kw/2,500rpm |
| Engine (*MC285CGRM-2) | Briggs & Stratton 3564 / Petrol |
| Engine Rated Output (MC285CGRM-2) | 10.8kw/2,600rpm |
| Electric Motor | 5.5kw, 4P 380V |
| Dimensions (MC285CWM-3) | 2,800mm (L) x 750mm (W) x 1,470mm (H) |
| Dimensions (MC285CWME-3) | 3,285mm (L) x 750mm (W) x 1,470mm (H) |
| Machine Weight (MC285CWM-3) | 1,990kg |
| Machine Weight (MC285CWME-3) | 2,160kg |
| Document |
All our cranes include a range of standard equipment that ensure the
safety, functionality and usability of the cranes are unsurpassed.
