Levertijd in overleg
| Capaciteit | 4.9t x 2.1m |
| Reikwijdte | 14.67m x 0.20t |
| Hefhoogte hoog | 16.50m |
| Hefhoogte laag | -25.0m |
| Pick & Carry Capacity | 2,000kg |
| Travel speed | 0-3.4km/h |
| Travel Ground Pressure | 47.8kPa (0.49kgf/cm2) [50.6kPa (0.52kgf/cm2) w/blade & fly jib] |
| Engine | ISUZU 4LE2XBJB / Diesel |
| Engine Rated Output | 44.6kW/2000min-1Â (60.6PS / 2000rpm) |
| Dimensions | 5,220mm (L) x 2,320mm (W) x 2,760mm (H) |
| Tail Swing | 1,390mm |
| Machine Weight | 9,790kg (10,190kg w/blade, 9,970kg w/fly jib, 10,370kg w/ blade & fly jib) |
| Document |
All our cranes include a range of standard equipment that ensure the
safety, functionality and usability of the cranes are unsurpassed.
