Levertijd in overleg
| Capaciteit | 8.1t x 2.8m |
| Reikwijdte | 19.23m x 0.34t |
| Hefhoogte hoog | 20.1m |
| Hefhoogte laag | -23.2m |
| Pick & Carry Capacity | 3,500kg |
| Travel speed | 0-3.1km/h |
| Travel Ground Pressure | 65.6kPa [0.67kgf/cm2] (67.3kPa ï¼»0.69kgf/cm2] with fly jib) |
| Travel Ground Pressure with Blade | 68.8kPa [0.70kgf/cm2] (70.5kPa ï¼»0.72kgf/cm2] with fly jib) |
| Engine | Yanmar 4TNV98CT / Diesel |
| Engine Rated Output | 52.3kw/2,100rpm |
| Dimensions | 7.380mm (L) x 2,490mm (W) x 3,015mm (H) |
| Tail Swing | 1,675mm |
| Machine Weight | 19,400kg (19,900kg with fly jib) |
| Machine Weight with Blade | 20,350kg (20,850kg with fly jib) |
| Document |
All our cranes include a range of standard equipment that ensure the
safety, functionality and usability of the cranes are unsurpassed.
