Levertijd in overleg
| Capaciteit | 6.0t x 2.6m |
| Reikwijdte | 16.1m |
| Hefhoogte hoog | 16.7m |
| Hefhoogte laag | -24.5m |
| Pick & Carry Capacity | 2,000kg |
| Travel speed | 0-3.1km/h |
| Travel Ground Pressure | 51.2kPa (0.52kgf/cm2) [54.5kPa (0.56kgf/cm2) w/blade & fly jib] |
| Engine | ISUZU 4LE2XBJB / Diesel |
| Engine Rated Output | 44.6kW/2000min-1 (60.6PS / 2000rpm) |
| Dimensions | 6,610mm (L) x 2,490mm (W) x 2,910mm (H) |
| Tail Swing | 1,550mm |
| Machine Weight | 15,030kg (15,710kg w/blade, 15,330kg w/fly jib, 16,010kg w/ blade & fly jib) |
| Document |
All our cranes include a range of standard equipment that ensure the
safety, functionality and usability of the cranes are unsurpassed.
